Iliotibial Band Syndrome

What is iliotibial band syndrome?

  • Iliotibial band syndrome is a condition that usually presents as pain on the outside of the knee. It normally occurs because of overload due to prolonged or repeated bouts of exercise.

How common is iliotibial band syndrome?

  • Iliotibial band syndrome is not common in the general population (1).
  • It does make up about 10% of injuries suffered by runners (2).
  • It can also occur in other sports and physical activity although less commonly.

Should I worry?

  • No.
  • With the right rehabilitation approach, iliotibial band syndrome generally recovers well without the need for further intervention (4).
  • It is not linked to other serious pathology.

Who is most likely to suffer from iliotibial band syndrome?

  • This condition is predominantly something that occurs in runners.
  • It can occur in those involved in all running-based sports.
  • It is more common in females (3, 7).

What are the common symptoms?

  • Pain on the side of the knee.
  • Pain is typically felt when loading the knee (walking/running).
  • If symptoms are significant, pain and stiffness may be present after long periods of inactivity.
  • Typically, pain will increase following a period of exercise (2).

What can I do?

  • Reduce the volume and intensity of your exercise (2).
  • Increase the flexibility of the muscles around the area.
  • Improve the strength/stability of the hip (5).
  • In some cases, a physiotherapist may assess your foot posture and recommend insoles.
  • Advice by a qualified physiotherapist will be helpful in most cases.

How long will it take to recover?

  • This will depend upon several factors including, but not limited to: the duration of symptoms, age, adherence to rehabilitation, amount of training you are attempting to complete.
  • We would expect to see improvement in symptoms within 2-3 months and certainly no longer than 3-4 months (2).
pure

1. Introduction

Iliotibial band syndrome is a condition that usually presents as pain on the outside of the knee. There is debate about the exact nature of the condition. Previously we believed that it was a friction syndrome, caused by rubbing over the bony part of the outside of the knee. More recently, however, we now understand that it is more of an impinging of the tissue at the side of the knee (1). This is important as it changes how we look to manage and ultimately resolve, the condition.

pure

2. Signs & Symptoms

The typical signs and symptoms of the condition are a sharp pain on the outside of the knee, particularly when the foot hits the floor (walking or running). There is unlikely to be any swelling and it is uncommon to have any ‘giving way’, locking or clicking with this condition. Some people will describe the pain as a throbbing or burning pain (5).

Most commonly pain is the main complaint, with stiffness becoming progressively more of a problem, particularly after periods of inactivity.

3. Causes

There are a number of possible causes of the condition but the most common are;

  • Hip muscle weakness – weakness of the hip muscles can increase the stress on the outside of the knee, particularly when you are fatigued from exercise (4).
  • Excessive training load – training load that your body is not accustomed to, or training that involves a significant amount of volume without sufficient rest, can cause a number of overuse conditions, in particular iliotibial band syndrome (7).
  • Poor running technique – typically running with what is termed a crossover gait can increase the load to the iliotibial band.
  • Poor foot mechanics – excessive or poor control of pronation (the way your foot and arches flatten to distribute force when landing) of the foot can also increase the load on the structure due to an increase of internal rotation of the tibia.
pure

4. Risk Factors

This is not an exhaustive list. These factors could increase the likelihood of someone developing iliotibial band syndrome. It does not mean everyone with these risk factors will develop symptoms.

pure

5. Prevalence

Iliotibial band syndrome is very rarely seen in the general population. It is one of the most common injuries in runners presenting with lateral knee pain, with an incidence estimated to be between 5% and 14% (2). Further studies indicate that iliotibial band syndrome is responsible for approximately 22% of all lower extremity injuries (9).

6. Assessment & Diagnosis

A musculoskeletal physiotherapist can provide you with an accurate and timely diagnosis by obtaining a detailed history of your symptoms. A series of physical tests might be performed as part of your assessment to rule out other potentially involved structures and gain a greater understanding of your physical abilities. Any tests we do will be considered alongside your symptoms to ensure we have an accurate working diagnosis

Your physiotherapist will want to know how your condition affects you day-to-day so that treatment can be tailored to your needs and personalised goals can be established. Intermittent reassessment will ascertain if you are making progress towards your goals and will allow appropriate adjustments to your treatment to be made.

It is rarely necessary in this condition to require any scans or X-rays to be done immediately as physiotherapy will most likely be the first line of treatment. If symptoms persist or get worse then an MRI scan may be used to understand what else could be causing the symptoms.

7. Self-Management

As part of the sessions with your physiotherapist, they will help you to understand your condition and what you need to do to help the recovery from your iliotibial band syndrome. This may include reducing the amount or type of activity, as well as other advice aimed at reducing your pain. It is important that you try and complete the exercises you are provided as regularly as possible to help with your recovery. Rehabilitation exercises are not always a quick fix, but if done consistently over weeks and months then they will, in most cases, make a significant difference.

pure

8. Rehabilitation

It is widely agreed that the best starting point in the management of iliotibial band syndrome is physiotherapy-led rehabilitation (2, 7, 8). This will focus on optimising the flexibility and strength of the hip and foot.

9. Iliotibial Band Syndrome Rehabilitation Plans

Early Plan

This programme focuses on better recruitment of the gluteal muscles, as well as increasing the flexibility of the thigh muscles and hip rotators. It must be understood that whilst pain during and after these exercises cannot be totally avoided, a significant increase in pain is not desirable and can in fact hinder progress. Pain should not exceed 3/10 on your perceived pain scale.

Early Plan - Rating

Intermediate Plan

More focus is given to the strength of the hip muscles and single-leg stability. Again, it must be understood that whilst pain during and after these exercises cannot be totally avoided, a significant increase in pain is not desirable and can in fact hinder progress. Pain should not exceed 4/10 on your perceived pain scale.

Intermediate Plan - Rating

Advanced Plan

This programme is a further progression with exercises that challenge the strength of the area in a way that prepares you for a normal level of training. Pain should not exceed 3/10 on your perceived pain scale.

Advanced Plan - Rating
pure

10. Return to Sport/Normal Life

This condition is common in runners but the success rate of treatment through physiotherapy is very high. In most cases, it will be possible to return to a normal level of activity on completion of a course of physiotherapy.

11. Other Treatment Options

Typically, exercise is the best strategy for dealing with iliotibial band syndrome. In the past, it was believed that techniques such as massage and ultrasound to the iliotibial band itself were effective. However, recent research brings this assumption into question.

Local use of radial shockwave therapy (RSWT) is believed to stimulate the healing of soft tissue and reduce the activation of pain receptors. Radial shockwave therapy has been shown to be effective as part of a rehabilitation programme for runners with iliotibial band syndrome (8).

pure

Book an Appointment

Please book an appointment with one of our physiotherapists if you think you are suffering from this condition and would like to find out more.

We have Pure Physiotherapy clinics across the country including Norwich, Dereham, Bolton, Manchester, Rochdale, Sheffield, Southampton and Barnsley. Please view our clinics to find the closest physiotherapy clinic for you.

References

  1. Geisler, Paul & Lazenby, Todd. (2016). Iliotibial Band Impingement Syndrome: An Evidence-Informed Clinical Paradigm Change. International Journal of Athletic Therapy and Training. 22. 1-30. 10.1123/ijatt.2016-0075.
  2. Baker RL, Fredericson M. Iliotibial Band Syndrome in Runners: Biomechanical Implications and Exercise Interventions. Physical médicine and réhabilitation clinics of North America, 2016; 27(1):53-77
  3. Christopher D. Stickley, Melanie M. Presuto, Kara N. Radzak, Christina M. Bourbeau, Ronald K. Hetzler; Dynamic Varus and the Development of Iliotibial Band Syndrome. J Athl Train 1 February 2018; 53 (2): 128–134.
  4. Robert L. Baker, Richard B. Souza, Mitchell J. Rauh, Michael Fredericson, Michael D. Rosenthal, Differences in Knee and Hip Adduction and Hip Muscle Activation in Runners With and Without Iliotibial Band Syndrome, PM&R, Volume 10, Issue 10, 2018, Pages 1032-1039,
  5. Peixin Shen, Dewei Mao, Cui Zhang, Wei Sun & Qipeng Song (2019) Effects of running biomechanics on the occurrence of iliotibial band syndrome in male runners during an eight-week running programme—a prospective study, Sports Biomechanics, DOI: 10.1080/14763141.2019.1584235
  6. McKay, J., Maffulli, N., Aicale, R. and Taunton, J., 2020. Iliotibial band syndrome rehabilitation in female runners: a pilot randomized study. Journal of Orthopaedic Surgery and Research, 15, pp.1-8.
  7. Brown, A.M., Zifchock, R.A., Lenhoff, M., Song, J. and Hillstrom, H.J., 2019. Hip muscle response to a fatiguing run in females with iliotibial band syndrome. Human movement science, 64, pp.181-190.
  8. Weckström K, Söderström J. Radial extracorporeal shockwave therapy compared with manual therapy in runners with iliotibial band syndrome, Journal of Back and Musculoskeletal Rehabilitation, 2016; 29(1):161-70. doi: 10.3233/BMR-150612.
  9. Lavine R. Iliotibial band friction syndrome. Current Reviews in Musculoskeletal Medicine, 2010; 3(1-4) :18–22
